H TYPE MILLING DRILLING HEAD DOUBLE HEADS

To be used for collet DIN 6499

External coolant supply

Collet is not included

The H Type Milling Drilling Head (Double Heads) is a high-performance angle head solution engineered for CNC turning centers and multi-task machining systems, including Mazak-compatible platforms. Designed with a dual-spindle configuration, it enables simultaneous or independent milling and drilling operations, significantly reducing cycle time and improving machining efficiency on complex workpieces. This milling drilling head is compatible with DIN 6499 collets, providing reliable tool clamping with excellent concentricity and repeatability. External coolant supply is supported, ensuring effective chip evacuation and thermal control during high-speed cutting operations. Note: collet is not included. The double-head design allows machining on two positions without repositioning the workpiece, making it ideal for precision parts processing in automotive, electronics, and medical manufacturing sectors. The rigid H-type structure minimizes vibration and deflection, maintaining tight tolerances even under demanding cutting conditions.
